    BOPP Film Lamination , Dry Poster Lamination Machine

    Ask Lasest Price
    Brand Name : Laiyi
    Certification : CE
    • Product Details
    • Company Profile

    BOPP Film Lamination , Dry Poster Lamination Machine

    BOPP Film Lamination Printing Machine , Dry Poster Lamination Machine


    1. Double-sided adhesive release papers


    Double-sided adhesive release papers and photo papers, etc

    2. Double-sided adhesive release papers

    Technical parameters

    Machine specification1200mm/1400mm/1700mm
    Effective widthMax1100mm/1300mm/1600mm
    Machine speed350m/min
    ExtruderLD-90mm/LD-100mm “Automatic lifting type extruder”
    Extruder power45-55kw
    Extruder outputMax 200kg/h or 250kg/h
    Used resinsCoated resins like LDPE/LLDPE/PP/EVA/EAA
    Coating thickness8-45μm
    Thickness uniformity≤±5%
    Unwinding diameterMax Φ1200mm
    Rewinding diameterMax Φ1200mm
    Basic materialPaper(35-200g/㎡)
    Tension controlFull automatic tension roller closed-loop constant tension control of unwinder and rewinder
    Control modeHuman-machine interface, extrusion thickness is automatically precision calculated by computer, whole machine linkage control
    Frequency converterImported AC digital vector control inverter
    Machine Dimension(L*W*H)19.2/13.2×(9.5-12)×4.5m

    3. Double-sided adhesive release papers

    Product Application

    Jiangsu Laiyi designs and manufactures extrusion laminating/coating lines on the strength of a thorough expertise in the co-extrusion of special polymers - customized and modular layout to meet the demand for special products; - chill-roll unit with precise temperature control - rapid cooling system - special winders and unwinders suitable for any final application.

    Jiangsu Laiyi extrusion and co-extrusion units at the forefront of technology, boasting a high manufacturing quality with components suitable for processing also corrosive polymers. we has focused on high performance extruders with special screw design for a wide range of materials like LDPE, SURLYN, EVA, EAA, PP, with customized solutions including different layers, sizes and die widths.

    4.Double-sided adhesive release papers

    Main Features

    1) Double Shaft-less paper roll stands suitable for 3-6 inch paper core,automatic lift ,easier operation .

    2) Auto splicer device realize paper in 150-300 m/min speed exchange without decrease machine line speed

    3) Ultrasonic type EPC system,makes frequent replacement materials operation more simple

    4) Hydraulic lamination structure design , can make coating thinner and firm .

    5) Trimming device make the finished coated paper rolls even

    6)Special cutting knife and rewinder design makes high speed rewinding shafts exchange possible
